Laboratory freezer SMU50

hospitalfor pharmaciesupright

Overview
Construction and materials: internal chamber in Scotch Brite stainless steel; ecological polyurethane insulation, thickness 110 mm; external structure in pre-painted aluminium with protective film (white PVC-coated steel also noted); solid door with fingerproof finish. Capacity: 50 L. Operating range: -40 / -86 °C.

Traceability and monitoring
Datalogger and alarms: Integrated high-precision datalogger records temperature and alarm events. USB port for easy data download. Battery backup for the alarm control unit and free contact for remote alarm are included to support continuous monitoring and traceability.

Product highlights / general info

• Type: Ultralow freezer
• Capacity: 50 L
• Temperature range: -40 / -86 °C
• Door: Solid
• Tag: outlet

Target

• Instruments Solutions: Life science; Health Care
• Life Science sector: Laboratory; Pharmaceutical; Petrochemical industry; Agro-food; Small laboratories
• Health Care sector: Hospital pharmacy; Analysis laboratory

Aesthetics

• Finish: Fingerproof

Technical features (summary)

• Temperature range: -40 / -86 °C
• Datalogger: Yes (integrated, USB download)
• Capacity: 50 L
• Lock: Standard
• Lateral passing hole: Included
• Battery backup for alarm control unit: Yes
• Free contact for remote alarm: Standard
• Insulation thickness: 110 mm
• Vaporisation: Static
• Refrigerant gases: R601, R600a, R290, R170, R1150, R50
• CFC Free: Yes

Performance / Energy

• Noise level: 51 dBA

Electrical connection

• Voltage: 230 V, 50 Hz
• Plug: (F;E) Schuko

Interface

• Display: LCD
• Alarm indicator on display: Yes
• Audible alarm: Yes
• Visible alarm: Yes
• USB port: Yes

Construction

• Door: Solid
• Chamber material: Scotch Brite stainless steel
• External material: Pre-painted aluminium with protective film (white PVC-coated steel noted in overview)
• Number of doors: 1
• Wheels: 4
• Number of compressors: 1

Technical specifications

• Model: SMU50
• Type: Ultralow freezer
• Capacity: 50 L
• Temperature range: -40 / -86 °C
• Insulation: 110 mm polyurethane
• Internal finish: Scotch Brite stainless steel
• External finish: Pre-painted aluminium with protective film (white PVC-coated steel noted in overview)
• Door: Solid (fingerproof finish)
• Datalogger: Integrated, with USB data download
• Alarms: visible, audible, alarm indicator on display, battery backup for control unit, free contact for remote alarm
• Vaporisation: Static
• Refrigerant gases: R601, R600a, R290, R170, R1150, R50
• CFC Free: Yes
• Voltage / Frequency: 230 V, 50 Hz
• Plug type: (F;E) Schuko
• Noise level: 51 dBA
• Number of doors: 1
• Number of wheels: 4
• Number of compressors: 1
