Automatic Western blot analyzer XD236

automated

Introduction
XD236 is an automatic Western Blot system designed for laboratory membrane‑strip assays. It automates temperature, incubation timing and reagent dispensing to support routine Western blot workflows while processing up to 36 strips per run.

Key features

• Programmable: ≥38+2 fixed programs; 20 steps × 6 working phases.
• Capacity: supports 1–36 (or 1–30) test strips per run.
• Liquid handling: standard 6‑channel pump, dispensing range 250–3000 μl (1 μl increment); pump accuracy ±3.0% at 2000 μl; precision CV ≤5.0% at 2000 μl.
• Temperature and agitation: selectable room/25/30/37/42 °C; shaker accuracy ±1.5 °C; 3 shaking speeds.
• Contamination control and safety: closed piping system and negative‑pressure suction nozzle reduce cross‑contamination risk.
• Maintenance and consumables: automatic rinsing/cleaning; reagent/wash/waste capacities: reagent 200 ml ×5; wash 1000 ml ×1; waste 2000 ml ×1 (airtight negative‑pressure).
• Interface and alarms: dot‑matrix LCD with backlight, RS232 communication; alarms for reagent dispensing, waste overflow and end of run.

Technical parameters
Model: XD236
Brand: BIOBASE
Test strip capacity: 1–36 or 1–30 strips
Programming capacity: ≥ 38+2 (fixed procedure)
Programmable steps: 20 steps × 6 phases
Dispensing system: standard 6‑channel pump
Dispensing range / increment: 250 μl–3000 μl, 1 μl increment
Pump accuracy: ±3.0% (at 2000 μl); precision CV ≤5.0% (at 2000 μl)
Incubation time / increment: 0–24 h / 1 min; display in h/min/s
Shaking speed: 3 gears optional
Shaker temperature control: accuracy ±1.5 °C; fluctuation ≤0.2 °C at 37 °C
Display: dot‑matrix LCD with backlight
Communication: RS232 (9600, 8N1)
Power supply: 110–240 V, 50/60 Hz, 250 VA
External size (W×D×H): 630×500×400 mm; Packed: 840×630×840 mm
Net weight: 33 kg; Gross weight: 70 kg

Usage and compliance

• Operating environment: indoor use, altitude ≤3000 m, 5–40 °C, RH ≤80% at temperature <31 °C.
• Cross‑contamination note: when negative and positive samples are run sequentially, negatives should not show positive bands.
• Operational options: program lock/unlock, pump quantitative correction, position check and automatic cleaning.
