Medical compressor HY serieslaboratorywith air dryeroil-free
Add to favorites
Compare this product
Characteristics
- Applications
- medical, laboratory
- Options and accessories
- oil-free, with air dryer, with soundproof housing
- Pressure
7.5 bar
(108.7783 psi)- Flow
Min.: 100 l/min
(26.42 us gal/min)Max.: 300 l/min
(79.25 us gal/min)- Power
Min.: 0.55 kW
(0.75 hp)Max.: 1.5 kW
(2.04 hp)- Weight
Min.: 24 kg
(52.9 lb)Max.: 70 kg
(154.3 lb)- Length
Min.: 42 cm
(16.5 in)Max.: 69 cm
(27.2 in)- Width
Min.: 39 cm
(15.4 in)Max.: 45 cm
(17.7 in)- Height
Min.: 60 cm
(23.6 in)Max.: 75 cm
(29.5 in)
Description
Overview
Features
Technical parameters (key values)
Applications / Notes
Specifications
- Brand: BIOBASE
- Product origin: China
- Delivery time: Within 7 days
- Supply capacity: Factory direct supply
Features
- Pure oil-free design: output gas contains no oil, protecting end gas equipment.
- Anti-rust tank body: internal tank wall finished and spray-coated with anti-corrosion and antibacterial treatment.
- Automatic control: pressure switch controls automatic start/stop.
- Easy operation: ready to use after power on.
- Simple maintenance: accessible components for routine maintenance.
- Optional accessories: muffler box, drying system and filtration system available to reduce noise, lower pressure dew point and improve filtration accuracy.
Technical parameters (key values)
- Models: HY-100 / HY-200 / HYT-200
- Max working pressure: 0.75 MPa
- Gas output: HY-100: 100 L/min; HY-200: 150 L/min; HYT-200: 300 L/min
- Rotation speed: 1450 rpm
- Tank capacity: HY-100: 24 L; HY-200: 38 L; HYT-200: 60 L
- Gas outlet: φ8 mm
- Power: HY-100: 550 W; HY-200: 750 W; HYT-200: 1500 W
- Power supply: Standard 220V 50Hz; optional 110V 60Hz
- Dimensions (L×W×H): HY-100: 420×420×600 mm; HY-200: 450×450×750 mm; HYT-200: 690×390×660 mm
- Net weight: HY-100: 24 kg; HY-200: 37 kg; HYT-200: 70 kg
- Packing size: HY-100: 470×470×650 mm; HY-200: 470×470×800 mm; HYT-200: 850×480×870 mm
- Gross weight: HY-100: 26 kg; HY-200: 40 kg; HYT-200: 78 kg
Applications / Notes
- Technical parameters are provided by the manufacturer's product table.
- Suitable for laboratory, medical and industrial applications where oil-free compressed air is required.
Specifications
- Available models: HY-100, HY-200, HYT-200
- Working pressure: 0.75 MPa
- Air flow range: 100–300 L/min (model dependent)
- Rotation speed: 1450 rpm
- Tank capacities: 24 / 38 / 60 L
- Power ratings: 550 / 750 / 1500 W
- Outlet diameter: 8 mm
- Power supply: 220V 50Hz (standard); 110V 60Hz (optional)
- Optional: muffler, drying and filtration systems
