Drying oven FOV-29

curingheatingfor scientific research

Product Overview
Labotemp Blast Drying Oven FOV-29 is a 400 L forced-air laboratory oven designed for precise drying, baking, curing and thermal processing in research laboratories, pharmaceutical facilities, universities, quality control departments and industrial environments. The oven provides reliable temperature control from RT+10°C to 300°C with 0.1°C resolution and ±1°C temperature fluctuation. The stainless-steel inner chamber resists corrosion and is easy to clean; the large double-layer tempered glass observation window permits sample monitoring during operation.

Design and Control
Engineered for continuous, long-term operation, the drying oven is fitted with an intelligent PID digital temperature controller featuring timer, over-temperature alarm, deviation correction and self-tuning for accurate process control. The hot-air circulation system uses a low-noise cooling fan to ensure uniform temperature distribution throughout the chamber. Fan speed is adjustable to adapt airflow to process requirements. The exterior is powder-coated cold-rolled steel and the heating system delivers 4500 W.

Key features

• Large 400 L capacity suitable for high-volume laboratory and industrial drying tasks.
• Uniform hot-air circulation with adjustable, fan-assisted airflow for consistent temperature distribution.
• Intelligent PID control with timer, self-tuning and over-temperature protection.

Features

• 400 L large capacity chamber.
• Intelligent PID temperature controller with digital display for accurate process control.
• Temperature self-tuning and deviation correction functions to improve heating stability.
• Built-in timer and over-temperature alarm for enhanced operational safety.
• Large double-layer tempered glass observation window for sample monitoring.
• Hot air circulation system with low-noise cooling fan for uniform chamber temperature.
• Adjustable fan speed control for airflow optimization.
• High-quality silicone door sealing strip for thermal insulation and long service life.
• Stainless steel inner chamber for corrosion resistance and easy cleaning.
• Powder-coated cold-rolled steel exterior for durability and appearance.
• Optimized airflow design for improved heat distribution and drying consistency.
• User-friendly control interface for simple operation and parameter adjustment.
• Designed for continuous laboratory and industrial drying applications; stable chamber construction minimizes temperature variation.
• Energy-efficient heating system for reliable long-term performance.

Applications

• Pharmaceutical Industry: Drying pharmaceutical ingredients, powders, granules and packaging materials.
• Research Laboratories: Sample preparation, thermal conditioning, moisture removal and experimental studies.
• Chemical Industry: Drying chemical compounds, catalysts and laboratory reagents.
• Electronics Manufacturing: PCB drying, electronic component conditioning and moisture elimination.
• Universities & Research Institutes: Academic research, material testing and engineering studies.
• Quality Control Laboratories: Product stability testing, heat resistance evaluation and routine inspection processes.
• Food & Agricultural Laboratories: Sample drying, moisture content analysis and quality assessment.
• Industrial Manufacturing: Component drying, curing, baking and low-temperature heat treatment applications.

Technical specifications

• Chamber Capacity: 400 L
• Temperature Range: RT+10°C to 300°C
• Temperature Resolution: 0.1°C
• Temperature Fluctuation: ±1°C
• Controller Type: Intelligent Digital PID Controller
• Heating Power: 4500 W
• Air Circulation System: Hot Air Circulation with Low-Noise Cooling Fan
• Fan Speed Control: Adjustable
• Chamber Material: Stainless Steel
• Exterior Material: Powder-Coated Cold-Rolled Steel
• Observation Window: Double-Layer Tempered Glass
• Temperature Functions: Self-Tuning, Deviation Correction
• Safety Features: Over-Temperature Alarm
• Internal Dimensions (W × D × H): 690 × 630 × 910 mm
• External Dimensions (W × D × H): 855 × 930 × 1085 mm
• Packaging Dimensions (W × D × H): 950 × 1010 × 1240 mm
• Net Weight / Gross Weight: 118 kg / 167 kg
