Thumb splint AM-OSN-U-22

waterproofwith flexible stays

Product overview
Breathable thumb splint AM-OSN-U-22 designed for treatment and immobilization of thumb injuries (sprains, ligament injuries and other soft tissue damage). The wrap-around design offers universal sizing and fits both hands. The splint provides effective immobilization while remaining more comfortable than a traditional plaster cast.

Features

• High-quality shapeable aluminum splint for excellent immobilization; splint can be gently moulded by a clinician to individual therapeutic needs.
• Wrap-around design ensures universal fit (one size) and fits both left and right hands.
• Slightly elastic UniPren™ fabric provides compression and temperature regulation to improve healing.
• Breathable construction using ActiveSpace™ spacer material for high skin ventilation and low moisture absorption.
• Latex-free and intended as a Class I medical device.

Materials
ActiveSpace™: a spacer, polyamide 3D lamination with high skin ventilation; lightweight, non-elastic, two-layer construction with polyamide braids between layers; permits air flow, minimal water and moisture absorption and is waterproof.

UniPren™: a 3-layer material with an external elastic polyamide cover knit with self-adhesive function, an internal neoprene foam core and an elastic jersey inner cover knit; soft, highly flexible, prevents imprinting on skin and abrasions in high compression areas; self-adhesive function simplifies use.

Stiffening
Flat aluminum stays made of a special aluminum alloy provide proper stiffness with minimal weight; rounded ends to prevent product damage; stays can be pre-profiled or flat and require individual bending to adapt to the patient when necessary.

Purpose of use

• Sprained thumb
• Thumb dislocation
• Trigger thumb
• Keeper thumb
• Thumb arthritis
• Gamekeeper's thumb
• DeQuervain's syndrome
• Stener lesion of the thumb
• Painful first carpometacarpal joint

Sizes
Table: Size | Wrist circumference | How to measure
Universal | min 11 – max 22 cm (min 4.3" – max 8.7") | measurement around wrist
Total length of product: 18 cm (7.1")

Technical specifications

• Brand: 4sport
• Code: AM-OSN-U-22
• Trade name: UPPER-EXTREMITY SUPPORT
• Model: AM-OSN-U-22
• Medical device class: Class I medical device
• Primary materials: ActiveSpace™ (spacer polyamide 3D lamination), UniPren™ (3-layer neoprene-based material)
• Stiffening: flat aluminum stay (shapeable)
• Size: Universal (wrist circumference min 11 – max 22 cm)
• Total length: 18 cm (7.1")
• Fits both left and right wrists
• Breathable, latex-free, double-sided design
