Medical software Paragon™

testfor the pharmaceutical industryanalysis

Overview
Paragon™ is bond test software for Nordson Test & Inspection platforms. Its intuitive, tab-based and configurable user interface provides direct access to test setup, automatic GR&R calculation, system diagnostics, a database search wizard and comprehensive reporting to support traceable bond-strength measurement workflows.

Quick and Easy to Use
The interface uses an efficient tab layout with test settings fixed to a left column and an easy-access toolbar for common actions (save, print, lights, zero). Training follows a linear workflow; configurable access modes and locking restrict operator changes while permitting supervisor control.

High Accuracy and Repeatability

• Intelligent system monitoring including life tests on tool, load cartridge and calibration jig
• Health checks, calibration status and cartridge initialization with automatic alerts

Image Capture for Advanced Analysis
Rapid acquisition of images at multiple magnifications supports failure-mode identification and links images to test records for traceability and investigation.

Flexible Analysis and Reporting
Data Analysis

• On-board statistics and Statistical Process Control (SPC) with histogram distribution views (mean and current samples)
• Force trend analysis (box-and-whisker, optional mini histogram)
• Grade Pareto analysis
• Loop-height trend analysis and force/time-displacement curves
• Statistical result metrics: mean, max/min range, standard deviation, mean ±3σ, Cpk and Cp

Efficient Testing
Test Automation
Automated testing of a complete row of bonds on a device/leadframe or multiple devices in hybrid packages. Pre-program test points, positions and pitch; store test patterns with images for quick selection.

New Standard of Advanced Automation
Paragon Automation
View automation patterns and wire/bumps/die locations simultaneously. Edit test patterns offline and preview animations of wire pulls, test order, test type and offsets prior to execution.

Matrix Automation Testing
Program a single device and extrapolate the pattern across a frame (Device Matrix) to generate multi-device test patterns automatically.

Resources & Downloads
Brochures, catalogs, product videos and technical literature are available for Paragon™ Software.

Features / Technical specifications

• Product name: Paragon™ Software
• Designed for bond testing (BT) with built-in GR&R calculation
• Integrated diagnostics and system health monitoring with automatic alerts
• Database search wizard for test data and patterns
• On-board SPC and advanced reporting
• Tab-based UI with configurable access modes and locking
• Image capture at multiple magnifications for failure analysis
• Force trend analysis, histograms, Pareto and loop-height trend tools
• Test automation including Device Matrix for multi-device frames
• Automation preview and wire-pull animations
