Ceiling-mounted surgical light SX-700/500

LEDfor operating rooms3-arm

Product
Ceiling-mounted LED surgical light with three articulating arms, integrated camera and monitor. Model SX-700/500 by Suxin Medical, designed for use in laminar-flow operating rooms and general surgical procedures.

Key features

• Fully enclosed, streamlined lamp head compatible with laminar-flow purification and OR hygiene requirements.
• Stable natural positioning with no drift; rotating arms provide 360° movement for flexible surgical access.
• Long-life LED cold-light source (≥50,000 h) with no infrared or ultraviolet radiation; minimal temperature rise at surgeon's head (<1℃).
• Adjustable color temperature 3700–5500 K and high color rendering index (CRI ≥96) to improve tissue visualization and reduce visual fatigue.
• Humanized surface design with touch control; digital brightness adjustment (displayed range: 1%–10%).

Technical parameters

• Model: LED 700/500 (SX-700/500)
• LED lamp beads qty: 80/48
• Illuminance (Lux): 40000–180000; 34000–140000
• Color temperature: 3700–5500 K (adjustable)
• Spot diameter: 150–300 mm
• Color Rendering Index (CRI): ≥96
• Irradiation depth: ≥1200 mm
• Brightness adjustment (digital): 1%–10%
• Power supply / Voltage: ~220V/50Hz (110V optional)
• Input power: 35 W
• Temperature rise at surgeon's head: <1℃
• LED lifetime: ≥50,000 h
• Recommended installation height: 2.8–3.2 m

Configuration

• Lampholder — 2 sets
• Disinfection handle — 4 pcs
• Lamp beads — 111 pcs
• Balancer — 2 sets
• Rotating arm — 1 set (double arms)
• Switch power supply assembly — 2 sets
• Fixed base — 1 set
• Shield — 1 set
• Light tools — 1 set
• Operating manual — 1 set

Product specifics

• Model: SX-700/500
• Brand: Suxin Medical
• HS code: 9405429000
