Polyamide wheel Levina

rubberpolypropyleneswiveling

Short description
The Levina swivel castor is designed for secure equipment mounting using a rectangular plate fitting (95 x 70 mm). The polyamide housing features a two-row ball-race swivel bearing and a slim fork profile. The wheel combines a polypropylene body with a thermoplastic rubber tread (87 Shore A) and a precision ball bearing to deliver low rolling resistance and floor protection. Wheel diameter 125 mm; overall height 165 mm. Dynamic load capacity 100 kg (up to 3 km/h); static load capacity 200 kg. Typical applications include medical equipment, catering trolleys, cleaning carts and mobile workstations.

Key features

• Wheel: thermoplastic rubber tread on polypropylene body (32 mm tread width)
• Bearing (wheel): precision ball bearing
• Threadguard: with threadguard for reduced maintenance
• Housing: polyamide, slim fork design (silver grey RAL7001)
• Fitting: rectangular plate, 95 x 70 mm (hole Ø 11 mm)
• Compliance: tested; RoHS / REACH compliant

Special features

• Non-hazardous materials: free from PAHs and chromium (VI)
• Quality control: tested in company laboratory for compliance with applicable standards
• Variable fitting options and colour-matching for product design integration
• High shock absorption and low abrasion for reduced maintenance
• Chemical resistance: components insensitive to many common cleaning agents
• Easy steering: two ball races in swivel bearing for smooth swivel action

Performance

• Roll performance: high — very good rolling characteristics
• Noise: low during movement
• Wear: reduced abrasion, good service life in typical applications
• Corrosion resistance: good for typical indoor applications (not stainless steel)

Specifications

• Product name / series: Levina
• Article / product number: 5370PJP125P51 7001
• S4 material number: 990036846
• EAN: 4031582347494
• Type: swivel castor
• Wheel diameter: 125 mm
• Overall height: 165 mm
• Overall width: 59 mm
• Tread / body width: 32 mm
• Tread hardness: 87 Shore A
• Wheel body material: polypropylene
• Tread material: thermoplastic rubber
• Wheel bearing: precision ball bearing
• Swivel bearing: two ball races
• Fitting type: rectangular plate
• Plate length x width: 95 x 70 mm
• Plate hole diameter: 11 mm
• Plate hole length (max): 50 mm
• Plate hole width (max): 75 mm
• Dome diameter: 59 mm
• Swivel interference: 201 mm
• Offset: 38 mm
• Swivel radius: 100.5 mm
• Load capacity (dynamic, up to 3 km/h): 100 kg
• Load capacity (static): 200 kg
• Overall weight: approx. 0.6 kg
• Temperature range: -10 °C to 40 °C
• Housing colour: Silver grey (RAL7001)
• Fork shape: slim
• Fork material: polyamide
• Standard: EN12530 - Devices Castors
