Medical trolley wheel Linea E-Lock

polyamidepolyurethaneswiveling

Short description
The TENTE Linea E-Lock swivel castor with directional lock is designed for medical and healthcare equipment requiring controlled straight travel and secure directional fixation. It features a polyamide twin-wheel housing, a polyamide wheel body with an injected polyurethane tread (92 Shore A) and precision ball bearings in both wheel and swivel for consistent rolling and smooth directional locking.

Product advantages

• Non-hazardous materials (RoHS & REACH compliant)
• Tested to applicable European device castor standards (EN12530)
• Colour matching options to integrate with equipment design
• Low-noise, non-marking tread suitable for clinical environments
• Ergonomic user controls for locking and unlocking

Features

• Wheel diameter: 100 mm
• Overall height: 120 mm
• Tread width: 20 mm
• Dynamic load (3 km/h): 120 kg
• Static load: 240 kg

Detailed description
The Linea E-Lock castor integrates a solid stem (round fitting) with a 22 mm diameter and 40 mm length for secure mounting. The twin-wheel polyamide fork reduces roll resistance while the injected polyurethane tread offers floor protection and quiet operation—important in patient-care areas and imaging rooms. Precision ball bearings in wheel hubs and the swivel raceway ensure reliable directional locking and smooth manoeuvrability at low speeds typical of medical trolleys and equipment.

Special features

• Materials free from polycyclic aromatic hydrocarbons and chromium (VI)
• Tested quality in in-house laboratory for compliance with standards
• User-friendly colour-coded pedals (green for directional lock, red for total lock)
• Paint finish options: gold, chrome or glossy colours
• Thread guards for reduced maintenance and unobstructed operation
• Integrated cable pusher to protect cables on the floor
• Options for conductive version to prevent electrostatic discharge
• Custom branding possible (engraved, cast or printed)

Technical specifications

• Product name / series: Linea (E-Lock)
• Article number: 5941UAP100R05-22 RAL9002
• EAN: 4031582368734
• Type: Swivel castor with directional lock
• Wheel diameter: 100 mm
• Tread width: 20 mm
• Tread material: Polyurethane, injected (92 Shore A)
• Body material (wheel / fork): Polyamide
• Wheel bearing: Precision ball bearing
• Swivel bearing: Precision ball bearing
• Overall width: 82 mm
• Overall height: 120 mm
• Overall weight: 0.92 kg
• Dynamic load (3 km/h): 120 kg
• Static load: 240 kg
• Temperature range: -10 °C to 40 °C
• Fitting: Solid stem, round (22 mm × 40 mm)
• Dome diameter: 52 mm
• Swivel interference: 216 mm
• Offset: 32 mm
• Swivel radius: 108 mm
• Threadguards: With threadguard
• Standard: EN12530 - Devices Castors
• Electric conductive: Optional
• Stainless: No
