Digital video microscope AM3111

for teachinginspectioneducation

Product overview
The AM3111 digital microscope (Dino-Lite) is a USB-connected imaging device providing smooth live imaging and balanced color, suitable for simple industrial inspections, educational use and hobby applications.

Key features

• Smooth imaging: CMOS sensor, VGA 640×480 resolution, up to 60 fps.
• Adjustable magnification: Variable 20x–50x for wide views and up to 200x for detailed close-ups; controlled via the focus knob.
• Lighting: 8 white LEDs with IR cut-filter (>650 nm) for visible-light imaging.
• Connectivity and software: USB 2.0 interface; compatible with DinoCapture 2.0 (Windows) and DinoXcope (Mac).

Optical data table
MAGNIFICATION RATE | WORKING DISTANCE (mm) | FIELD OF VIEW (X) (mm) | FIELD OF VIEW (Y) (mm) | DEPTH OF FIELD (mm)
20x | 64 | 20 | 15 | 14
30x | 34 | 13 | 10 | 7
40x | 20 | 10 | 7 | 4
50x | 13 | 8 | 6 | 3
200x | 5 | 2 | 1 | 0.3

Specifications
Lighting

• Light / LED type: White
• Number of LEDs: 8
• Infrared filter: IR cut-filter >650 nm
• Diffuser available: No
• Emission filter: No
• Polarizer: No

Optics

• Magnification: 20x–50x; additional setting up to 200x
• Macro zoom: No
• Working distance: standard values as in optical table
• Lens type: Glass with anti-reflection coating

Sensor

• Sensor type: CMOS
• Resolution: VGA (640×480)
• Maximum frame rate: 60 fps

Compatibility

• Interface: USB 2.0
• Operating systems: Windows 7, 8, 10, 11; MacOS 10.9 and up
• Software: DinoCapture 2.0 (Windows), DinoXcope (Mac)
• Imaging standards: DirectShow, UVC
• WiFi: No

Housing

• Housing material: Composite / plastic
• Magnification lock: No
• Dimensions: 10.5 cm (L) × 3.2 cm (D)
• Weight: 94 g
• Cable length: 1.8 m

Features

• Special feature: No
• Measurement: No
• Calibration: No
• Microtouch sensor: No
• ESD safe: No

Information

• Package contents: Microscope, software CD, user manual
• Warranty information: 2 years European warranty
• Regulatory approval: CE, FCC, ROHS
• Price range shown: €150.00 - €250.00

Technical specifications

• Model: AM3111
• Brand: Dino-Lite
• Magnification range: 20x–50x (and up to 200x)
• Working distance examples: 64 mm (20x) to 5 mm (200x)
• Field of view examples (X × Y): 20 mm × 15 mm (20x) to 2 mm × 1 mm (200x)
• Depth of field examples: 14 mm (20x) to 0.3 mm (200x)
• Sensor: CMOS, VGA 640×480
• Max frame rate: 60 fps
• Illumination: 8 white LEDs, IR cut-filter >650 nm
• Lens: Glass with anti-reflection coating
• Interface: USB 2.0
• OS compatibility: Windows 7/8/10/11, MacOS 10.9+
• Software: DinoCapture 2.0 (Windows), DinoXcope (Mac)
• Housing: Composite / plastic
• Dimensions & weight: 10.5 cm × 3.2 cm; 94 g
• Cable length: 1.8 m
• Package: Microscope, software CD, user manual
• Warranty: 2 years (Europe)
• Certifications: CE, FCC, ROHS
