Digital video microscope AM4517MT-RFYW

for biologyfluorescenceLED fluorescence

Product description
Detect red fluorescence emissions with the AM4517MT-RFYW high-sensitivity 20x ~ 220x digital microscope. It provides 575 nm excitation lights and a 615 nm ~ 650 nm emission filter, capturing emissions from fluorescent probes such as mCherry, Alexa Fluor 594, and Texas Red. This model features Automatic Magnification Readout (AMR) for simplified measurements and supports switchable white light for conventional observation.

Main features

• 1.3 Megapixel CMOS sensor (1280x960)
• High-sensitivity detection optimized for red fluorophores
• 575 nm excitation; 615–650 nm emission filter
• 7 fluorescence LEDs + 1 white LED, LED on/off switchable
• Magnification range: 20x ~ 220x with Automatic Magnification Readout (AMR)
• Magnification lock; metal housing; measurement and calibration functions
• USB 2.0 interface; up to 30 fps
• Compatible software: DinoCapture 2.0 (Windows), DinoXcope (Mac)

Optical data table
Magnification Rate | Working Distance* | Field of View(x) | Field of View(y) | Depth of Field
20x | 59.8 | 19.53 | 14.65 | 7.05
30x | 33.1 | 13.02 | 9.77 | 3.36
40x | 20.5 | 9.77 | 7.32 | 2.02
50x | 13.4 | 7.81 | 5.86 | 1.38
60x | 9.2 | 6.51 | 4.88 | 1.01
70x | 6.7 | 5.58 | 4.19 | 0.79
80x | 5.1 | 4.88 | 3.66 | 0.64
90x | 4.1 | 4.34 | 3.26 | 0.53
100x | 3.7 | 3.91 | 2.93 | 0.45
110x | 3.6 | 3.55 | 2.66 | 0.39
120x | 3.7 | 3.26 | 2.44 | 0.34
130x | 4.1 | 3.01 | 2.25 | 0.30
140x | 4.5 | 2.79 | 2.09 | 0.27
150x | 5.2 | 2.60 | 1.95 | 0.25
160x | 5.9 | 2.44 | 1.83 | 0.22
170x | 6.7 | 2.30 | 1.72 | 0.21
180x | 7.5 | 2.17 | 1.63 | 0.19
190x | 8.5 | 2.06 | 1.54 | 0.18
200x | 9.4 | 1.95 | 1.46 | 0.16
210x | 10.5 | 1.86 | 1.40 | 0.15
220x | 11.5 | 1.78 | 1.33 | 0.14

Technical specifications

• Lighting: 575 nm excitation + white
• Number of LEDs: 7 FL + 1 White
• LED on/off switchable: Yes
• Infrared filter: No
• Diffuser: No
• Emission filter: 615 nm ~ 650 nm
• Fluorophores: mCherry, Alexa Fluor 594, Texas Red
• Magnification: 20x ~ 220x
• Lens type: Glass with anti-reflection coating
• Sensor type: CMOS, 1.3 MP (1280x960)
• Maximum frame rate: 30 fps
• Interface: USB 2.0
• Operating systems: Windows 7, 8, 10, 11; macOS 10.9+
• Software: DinoCapture 2.0 (Windows), DinoXcope (Mac)
• Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
• Supported video formats (Windows): WMV, FLV, SWF
• Supported image formats (Mac): JPEG, PNG
• Supported video formats (Mac): MOV
• Housing material: Metal
• Magnification lock: Yes
• Dimensions: 104 mm (H) x 32 mm (D)
• Weight: 90 g
• Cable length: 1.8 m
• Special feature: Automatic Magnification Readout (AMR)
• Measurement & calibration: Yes
• Microtouch sensor: Yes
• Package contents: Microscope, carry pouch, calibration target, user manual, N3C-C (Close Cap), N3C-EB (Extended Open Black Cap), N3C-LB (Black Long Cap), N3C-OB (Black Open Cap)
• Warranty: 2 years European warranty
• Regulatory: CE, FCC, ROHS
• Price range: €1200.00 - €1400.00
