Digital video microscope AM4517MT-G2FBW

for life sciences applicationsclinicalfor research

Overview
Designed for detection of green fluorescence emissions in life-science and clinical research, the AM4517MT-G2FBW is a high-sensitivity digital fluorescence microscope with an approximate magnification range of 20x–220x. It employs 465 nm excitation LEDs and a 510–545 nm band-pass emission filter, suitable for common green probes such as GFP, FITC and YFP. The unit includes AMR (Auto Measurement Reference) to simplify measurement workflows.

Key features

• High-sensitivity fluorescence digital microscope
• Excitation: 465 nm (λ peak)
• Emission filter: 510 nm–545 nm (band-pass)
• Detects green probes: GFP, FITC, YFP
• Magnification: approx. 20x–220x
• AMR (Auto Measurement Reference) for simplified measurements
• Camera resolution: 1.3 MP
• Illumination: 8 LEDs
• Interface: USB 2.0
• Metal housing
• Magnification lock

Additional visual/data elements
Includes excitation and emission spectra graph plus product icons indicating camera resolution, illumination, magnification range, USB interface, measurement capability, metal housing, magnification lock and fluorescence function.

Optical Data Table
MAGNIFICATION RATE | WORKING DISTANCE * | FIELD OF VIEW (X) | FIELD OF VIEW (Y) | DEPTH OF FIELD
20 | 59.8 | 19.53 | 14.65 | 7.05
30 | 33.1 | 13.02 | 9.77 | 3.36
40 | 20.5 | 9.77 | 7.32 | 2.02
50 | 13.4 | 7.81 | 5.86 | 1.38
60 | 9.2 | 6.51 | 4.88 | 1.01
70 | 6.7 | 5.58 | 4.19 | 0.79
80 | 5.1 | 4.88 | 3.66 | 0.64
90 | 4.1 | 4.34 | 3.26 | 0.53
100 | 3.7 | 3.91 | 2.93 | 0.45
110 | 3.6 | 3.55 | 2.66 | 0.39
120 | 3.7 | 3.26 | 2.44 | 0.34
130 | 4.1 | 3.01 | 2.25 | 0.30
140 | 4.5 | 2.79 | 2.09 | 0.27
150 | 5.2 | 2.60 | 1.95 | 0.25
160 | 5.9 | 2.44 | 1.83 | 0.22
170 | 6.7 | 2.30 | 1.72 | 0.21
180 | 7.5 | 2.17 | 1.63 | 0.19
190 | 8.5 | 2.06 | 1.54 | 0.18
200 | 9.4 | 1.95 | 1.46 | 0.16
210 | 10.5 | 1.86 | 1.40 | 0.15
220 | 11.5 | 1.78 | 1.33 | 0.14

Note: Listed values may differ slightly. * Without front cap. Unit = mm

Technical specifications

• Model: AM4517MT-G2FBW
• Magnification: approx. 20x–220x
• Excitation peak: 465 nm
• Emission filter: 510 nm–545 nm (band-pass)
• Fluorescence detection: GFP, FITC, YFP (green fluorescence)
• Camera resolution: 1.3 MP
• Illumination: 8 LEDs
• Interface: USB 2.0
• Measurement capability: AMR (Auto Measurement Reference)
• Housing: metal
• Magnification lock: yes
• Optical data: see Optical Data Table above (units in mm)
